Product Details
＋Make superb sound reproduction with high SPL a reality with the FC Series Coaxial Speakers
The UV protected low mass woven fiber cone bounces on a Cloth Nomex Spider producing 91dB sensitivity and is bonded to a surround of soft flexible Butyl rubber assuring smooth, fast, hard hitting sonic playback.
The built-in 6dB X Over blends highs and lows together with a balance not obtained by its competition. Large Ferro Fluid Cooled 20mm soft silk dome tweeters come with mounted coaxial style for easy installation helping the FC6X extend its playback up to 10K with a precise balance between power handling, frequency response and speaker location.
Manuals & Downloads
FEATURES
- Heavy Gauge Steel Basket with Thick Powder Coating
- 6.5 Inch Drivers with High-Energy Y30 Magnets
- MASSIVE Punched Logo
- High Sensitivity And Accurate Sound Reproduction
- Built-In 6dB Crossovers
- Custom Designed Pole Piece for Low Distortion and Sound Quality
- Two Piece Custom Paintable Metal Grills
- Rugged Construction to Withstand Harsh Mobile Environment
- Woven Fiber Paper Cone With Butyl Rubber Surround
- Fully Isolated Tinsel Leads to Eliminate Crosstalk
- High Quality Cloth Spider with Polyester Fiber
- 1” High Temperature KSV Voice Coil
- 20mm Silk Diaphragm Tweeter With Ferro Fluid Cooled V.C.
SPECIFICATIONS
| Speaker Size | 6.5" |
| Tweeter | 20mm Silk Diaphragm Tweeter With Ferro Fluid |
| Cone | Woven Fiber Paper Cone |
| Sensitivity | 91dB |
| Frequency | 58-10KHz |
| RMS Power | 75watts |
| Peak Power | 150 watts |
| Impedance | 4 Ohm |
| Mounting Depth | 2.4" |
| Mounting Diameter | 5.65" |
| Frame Diameter | 6.5" |
